VNA Configurator

Customer Name

Building Construction is
New Existing

Freezer Application
Freezer

Pallet Depth Max (J) (mm)

Pallet Width Max (K) (mm)

Pallet Height Max (mm)

Pallet Weight Max (kg)

Pallet Depth Min (mm)

Pallet Width Min (mm)

Pallet Height Min (mm)

Pallet Weight Min (kg)

Length of Aisle (meters)

Aisle Width Min (A) (mm)
Rack to Rack Dimension (C) (mm)
Top Beam (mm)

Rail Guidance System

Rail to Rail Dimension (mm)

Rail Height (mm)

Wire Guidance

Clear Door Height which truck needs to drive under (mm)

Height of Obstruction in Aisle (mm)

Mast Type, Duplex Mast Triplex Mast

Top of Fork H	Aux H9	Closed H1	Platform H12
1234 mm	1980 mm	5000 mm	5000 mm
2345 mm	2140 mm	5000 mm	5000 mm
3456 mm	2720 mm	5000 mm	5000 mm
4567 mm	3000 mm	5000 mm	5000 mm

Pick vs Pallet

Number of Shifts

Hours worked per day

Minimum Floor Requirements

	Floor Flatness	TR34
a.	2.6 mm	Difference in elevation between center line of front wheels
b.	1.95 mm	Rate of change for each 1ft of forward travel in elevation between centre line of front wheels
c.	4.54 mm	Difference in elevation in forward direction
d.	4.13 mm	Rate of change for each 1 ft of forward travel in elevation between front and rear

Floor Requirements for maximum performance VDMA

	Floor Flatness	VDMA
a.		Difference in elevation between center line of front wheels
c.		FX Value

PDF Output

Description	Override Option	Novo Code
Cabin		OPP012
Chassis		OPP012
